General Specifications
-
Transducers 8x 2.75”(70mm) woofers, 2x 1”(25mm) Tweeters, 4 x 7.2"(182.8mm) x3"(76.2mm) Racetrack Passive Radiators
Output Power 300WRMS, 600W PEAK (IEC60268)
THD at Rated RMS Power < 1%
Voltage Range: 9.6 - 16VDC Quiescent Current Draw < 0.9A
Maximum Current Draw 40A
Frequency response 45Hz-40kHz
Signal-to-noise Ratio > 80 dB
Cable type 10 AWG
Cable length 12 Feet (3.66m)
Bluetooth® Version 5.3
Bluetooth® profile A2DP V1.3, AVRCP V1.6
Bluetooth® transmitter frequency range 2400 MHz – 2483.5 MHz
Bluetooth® transmitter power ≤ 15 dBm (EIRP)
Aux-In 2Vrms(0.35Vrms - 2Vrms), 4Vrms(0.7Vrms - 4Vrms), 6Vrms(1.05Vrms - 6Vrms) (3.5 mm connector)
Aux-Out 2 Vrms (3.5 mm connector)
USB format FAT16, FAT32
Soundbar Dimension (L x W x H) 35-11/32" x 5" x 4-5/8" (897.5 x 126.7 x 118mm)
Soundbar Weight 20.83 lbs (9.45 kg)
Packaging dimensions (W x H x D) 38.2" x 9" x 7.6" (971 x 229 x 193mm)
Gross weight 27.5 lbs (12.52 kg)
- 1x Soundbar
- 2x Security cables
- 1x Small Wrench
- 1x L-Small Allen wrench
- 1x T-handle hex wrench
- 2x Straps with Velcro
- 1x G-Clamp
- 1x Keychain
- 1x 12ft (3.66m) power/ground wire harness
- 2x Rubber top covers
- 2x Mount cleats
- 2x Short M8 screws
- 2x Short M5 screws
- 2x Long M5 screws
- 2x M5 screw nuts
- 4x Flat washers
- 2x C-Clamps (2”)
- 2x C-Clamps (1.75”)
- 2x Thick rubber strips (for 1.5” pole)
- 2x Thin rubber strips (for 2” & 1.75” pole)
- 1x Quick start guide
- 1x Safety sheet & warranty card
