General Specifications
-
Transducers
4x 2.75”(70mm) woofers, 2x 1”(25mm) tweeters, 2x 7.2”(182.8mm) x3”(76.2mm) Racetrack Passive Radiators Output Power
150WRMS, 300W PEAK (IEC60268) THD at Rated RMS Power
< 1% Voltage Range: 9.6 - 16VDC
9.6 - 16VDC Quiescent Current Draw
< 0.9A Maximum Current Draw
25A Frequency response
45Hz-40kHz Signal-to-noise Ratio
> 80 dB Cable type
12AWG Cable length
12 Feet (3.66m) Bluetooth® Version
5.3 Bluetooth® profile
A2DP V1.3, AVRCP V1.6 Bluetooth® transmitter frequency range
2400 MHz – 2483.5 MHz Bluetooth® transmitter power
≤ 15 dBm (EIRP) Aux-In
2Vrms(0.35Vrms - 2Vrms), 4Vrms(0.7Vrms - 4Vrms), 6Vrms(1.05Vrms - 6Vrms) (3.5 mm connector) Aux-Out
2 Vrms (3.5 mm connector) USB format
FAT16, FAT32 Soundbar Dimension (L x W x H)
21-5/32" x 5" x 4-5/8" (537.5 x 126.7 x 118mm) Soundbar Weight
11.57 lbs (5.25kg) Packaging dimensions (W x H x D)
24" x 9" x 7.6" (611 x 229 x 193mm) Gross weight
17.14 lbs (7.79 kg) -
- 1x Soundbar
- 2x Security cables
- 1x Small Wrench
- 1x L-Small Allen wrench
- 1x T-handle hex wrench
- 2x Straps with Velcro
- 1x G-Clamp
- 1x Keychain
- 1x 12ft (3.66m) power/ground wire harness
- 2x Rubber top covers
- 2x Mount cleats
- 2x Short M8 screws
- 2x Short M5 screws
- 2x Long M5 screws
- 2x M5 screw nuts
- 4x Flat washers
- 2x C-Clamps (2”)
- 2x C-Clamps (1.75”)
- 2x Thick rubber strips (for 1.5” pole)
- 2x Thin rubber strips (for 2” &1.75” pole)
- 1x Quick start guide
- 1x Safety sheet &warranty card
